2SM - 2SM Optos HP Pump, 1/8" Head SS

2SM - 2SM Optos HP Pump, 1/8" Head SS

SKU:
2SM
$3,450.00
universal power supply & US power cord
Current Stock:
Adding to cart… The item has been added
Description

Optos precision, high pressure metering pump model 2SM, Material of construction 316SS

Flow Rate* (mL/min): 0.01 – 10

Max. Pressure (psi): 6000

Piston Diameter (in.): 1/8

Piston Stroke (in.): .250

Wetted Parts: type 316 stainless steel, sapphire, ruby, graphite fiber reinforced PTFE, CTFE.

Reproducibility: typically +/-0.3%

Viscosity Limit: 500 centipoise

Tubing Connections:

  • Inlet valves: 1/4″-28 low pressure plastic fitting for use with 1/8″ plastic tubing (fitting and 60cm of tubing provided with pump).
  • Outlet valves: 10-32 tube nut, ferrule for use with 1/16″ tubing (tube nut and ferrule provided with pump).
  • Valves with special fittings available on request.

Remote Control Options:

  • Voltage: 0-5VDC
  • Current Loop: 4-20 mA
  • RS232

Dimensions (DxWxH): 28 x 10 x 23.5 cm (11 x 4 x 9.25 in.)

Weight: 5.3 kg (11.75 lbs.)

Electrical:

  • Voltage/Frequency: 100-230VAC (?10%); 50/60Hz
  • VA rating: 80
  • Fuse: 0.8 A

*Maximum flow rate specifications are based on theoretical volume displacement; actual flow rates will vary depending on such factors as fluid viscosity, compressibility and temperature.
